Voltage Jumper selectable

 95-132V ac or

 190-264V ac

 Frequency 50-60 Hz nominal

 Phase 1

OUTPUT

 Voltage max 90V dc at 207V ac input

 Current continuous 4 A dc

 Intermittent 6 A for 10 secs

 Resistance 15 ohms minimum

REGULATION

+/- 1.0% (see note 1)

THERMAL DRIFT

0.05% per deg. C change in AVR ambient (note 2)

TYPICAL SYSTEM RESPONSE

 AVR response 20 ms

Filed current to 90% 80 ms

 Machine Volts to 97% 300 ms

EXTERNAL VOLTAGE ADJUSTMENT

+/-10% with 1 k ohm 1 watt trimmer (see no
